| Application area | Specialization | Purpose | Measured gases | Device type | Model | |
| Oil and gas industry (about 60% of gas analyzers market) | Drilling sites | Continuous monitoring of pre-explosive concentrations of flammable gases CH, as well as the MPC of associated toxic gases, such as H2S, O2, etc. | CH, CH4, H2S, O2 | Stationary |
GAOS SENSON-SD-7031 and 7033 with or without controller GAOS SENSON-K-xM |
|
| GAOS SENSON-SV-5021 and 5023 | ||||||
| Control of pre-explosive concentrations of flammable gases CH, as well as the MPC of associated toxic gases, such as H2S, O2, etc. when working in the work area by maintenance personnel | Portable |
GAOS SENSON-V-1001, GAOS SENSON-2V-1003, GAOS SENSON -M |
||||
| Oil and gas pipelines | Control of pre-explosive concentrations of combustible gas CH, as well as the MPC of associated toxic gases, such as H2S, O2, CH3OH | CH, CH4, H2S, O2 | Portable |
GAOS SENSON-V-1001, GAOS SENSON-2V-1003, GAOS SENSON-M |
||
| Technological control in the pipeline | CH, CH4, H2S, O2, CH3OH | Stationary | GAOS SENSON-SD-7033-01 | |||
| O2, CH3OH | Portable | GAOS SENSON-V-1002 | ||||
| Oil Refineries | Control of pre-explosive concentrations of flammable gases CH, as well as the MPC of associated toxic gases, such as H2S, O2, etc. | CH, CH4, H2, H2S, O2, CO, CO2 | Stationary |
GAOS SENSON-SD-7031 and 7033 with or without controller GAOS SENSON-K-xM |
||
| CH, CH4, H2, H2S,O2, CO, CO2, NO, NO2 | Stationary | GAOS SENSON-SV-5021 and 5023 | ||||
| CH, CH4, H2, H2S, O2, CO, CO2 | Portable |
GAOS SENSON-V-1001, GAOS SENSON 2V-1003, GAOS SENSON-M |
||||
| Technological control | CH, H2, O2 | Stationary | GAOS SENSON-SD-7034 | |||
| CH, O2 | Portable | GAOS SENSON-V-1002 | ||||
| Gas service regional companies | Control of CH4 and CO | CH4, CO | Stationary | GAOS SENSON-SD-7031, 7032 and 7033 with or without controller GAOS SENSON-K-xM | ||
| GAOS SENSON-SV-5021, 5022 and 5023 | ||||||
| Other objects (gas stations, oil storages) | Control of pre-explosive concentrations of flammable gases CH | СН, СН4 | Stationary | GAOS SENSON-SD-7031, 7032 and 7033 with or without controller GAOS SENSON-K-xM | ||
| GAOS SENSON-SV-5021, 5022 and 5023 | ||||||
| Housing and communal services | Wastewater pumping station | Continuous monitoring of pre-explosive concentrations of CH4 and MPC of toxic gases | CH4, H2S,O2, CO, CO2, Cl2 | Stationary |
GAOS SENSON-SD-7032 and 7033 with or without controller GAOS SENSON-K-xM |
|
| Collectors, wells, reservoirs | Inspection during work in wells | CH4, H2S, O2, CO, CO2, NH3, Cl2 | Portable | GAOS SENSON-M and floating probe | ||
| Boiler houses | Control of CH4 and CO | CH4, CO | Stationary |
GAOS SENSON-SD-7032 and 7033 with or without controller GAOS SENSON-K-xM |
||
| Exhaust gas control | СН4, СО, О2, NO2, NO, SO2 | Stationary | GAOS SENSON-SV-5022 and 5023 | |||
| Emergency rescue services | Collectors, wells, objects with air pollution | Ensuring safety during rescue operations | All gases | Portable | GAOS SENSON-M with or without probes | |
| Power industry | TPP, NPP, HPP, СPP | Control of pre-explosive concentrations of flammable gases of H2, O2 level in the working area | H2, O2 | Stationary | GAOS SENSON-SD-7031, 7032 and 7033 with or without controller GAOS SENSON-K-xM | |
| Electrolysis areas | Control of H2 and O2 in process gas lines | H2, O2 | Stationary | GAOS SENSON-SD-7033-01 | ||
| Metallurgy | Metallurgical plants | Control of pre-explosive concentrations in the working area of CH and H2, MPC of toxic gases and the level of O2 | Н2, СН, СО, О2, NO2, NO, SO2 | Stationary | GAOS SENSON-SD-7031, 7032 and 7033 with or without controller GAOS SENSON-K-xM | |
| GAOS SENSON-SV-5021 and 5023 | ||||||
| Portable |
GAOS SENSON-V-1001, GAOS SENSON-2V-1003, GAOS SENSON-M |
|||||
| Exhaust gas control, H2 and O2 control in electrolysis gas lines | Stationary | GAOS SENSON-SD-7033-01 | ||||
| Transport | Parking, underground garages | Control of CO | СО | Stationary | GAOS SENSON-SV-5024 | |
| Motor transport, including special (gas composition in the cab) | Control of CO | СО | Stationary | GAOS SENSON-SV-5024 | ||
| Assessment of workplaces | NO, NO2, CO, O2, CH | Portable | GAOS SENSON-M with or without probes | |||
| Mining industry | Mines | Pre-explosive concentrations of CH4, MPC of toxic gases and control of O2 level | NO, NO2, CO, O2, CH, SO2, CO2 | Stationary | GAOS SENSON-SD-7031, 7032 and 7033 with or without controller GAOS SENSON-K-xM | |
| CH4 | Portable | GAOS SENSON-V-1001 | ||||
| Geology | Gas-geochemical search for oil fields | Hydrocarbons | CH | Portable | GAOS SENSON-M-3001 and 3004 | |
| Sea transport | Ships and moorings | Hydrocarbons, oxygen, oxides of nitrogen, CO | CH, O2, NO, NO2, CO, CO2 | Portable for holds and stationary for premises | GAOS SENSON-M-3001 and 3003 | |
| Heavy and light industry | Any production working with chemicals and fuels and lubricants (gasoline, varnishes, paints, adhesives, etc.), as well as their storage. As well as a complete set of gas analytical equipment of industrial complexes | Control of pre-explosive concentrations of flammable gases, control of MPC of toxic gases | All gases | Stationary | GAOS SENSON-SD-7031, 7032 and 7033 with or without controller GAOS SENSON-K-xM | |
| GAOS SENSON-SV-5021 and 5023 | ||||||
| Portable |
GAOS SENSON-V-1001, GAOS SENSON-2V-1003, GAOS SENSON-M |
|||||
| Medical industry | Oxygen cylinder storage rooms | Control of O2 | O2 | Stationary | GAOS SENSON-SV-5022 | |
| Agricultural industry | Processing of raw materials, control of early ignition of grain, livestock | Control of toxic gases in barns, poultry houses, granaries, etc. | NH3, CO2, O2, CH4, Cl2 | Stationary | GAOS SENSON-SD-7031, 7032 and 7033 with or without controller GAOS SENSON-K-xM | |
| GAOS SENSON-SV-5021 and 5023 | ||||||
| Portable |
GAOS SENSON-V-1001, GAOS SENSON-2V-1003, GAOS SENSON-M |
|||||
| Food production | Food, Beverage, Alcohol | Control of pre-explosive concentrations of flammable gases and MPC of toxic gases during production | H2, CH, CO2, CO, O2, Cl2, HCl, NH3 | Stationary | GAOS SENSON-SD-7031, 7032 and 7033 with or without controller GAOS SENSON-K-xM | |
| GAOS SENSON-SV-5021 and 5023 | ||||||
| C2H5OH | Portable |
GAOS SENSON-V-1001, GAOS SENSON-2V-1003, GAOS SENSON-M |
||||
| Ecology | Main low pollutants | Assessment of workplaces | All gases | Portable | GAOS SENSON-M-3002 | |
| Engineering companies | Design and engineering of production facilities and urban infrastructure | Inclusion of gas control systems for measuring flammable and toxic substances into project documentation | All gases | Stationary | All stationary | |
|
|
|
|
|
