Spectral range |
5 700 – 470 cm-1 with MG-32M detector 8 500 – 470 cm-1 with DLaTGS detector 6 000 – 600 cm-1 with MCT detector
|
|||
Beam splitter |
ZnSe |
|||
Interferometer |
Double Cat’s Eye |
|||
Detector |
MG-32M, DLaTGS, MCT |
|||
Spectral resolution |
0.5 cm-1 |
|||
Signal-to-noise ratio with the pyroelectric detector |
≥ 40 000 RMS (range 2 200 – 2 000 cm-1, per 1 min, resolution 4 cm-1) |
|||
Weight |
15 kg |
|||
Dimensions of main unit |
34 × 20 × 38 cm |
|
|
|
